Vmaxpower High quality ang services Inverter with charger digital display off-grid system with load sine wave

Short Description:

The Inverter can convert the low-voltage direct current into alternating current. It is composed of inverter bridge, control logic and filter circuit and other accessories. It Widely used in air conditioning, home theater, electric tools, sewing machine, DVD, VCD, computer, TV, refrigerator, video recorder, fans, lighting and so on.

Application: Home

Display: Digital display

Nominal Input Voltage: 220VAC±3%

Nominal Input Frequency: 50Hz/60Hz(Autodetection)

Output Frequency: 50HZ-60HZ Adjustable

Output Waveform: Pure Sine wave

Operating Mode: Normal, Energy Saving

Transfer Time: ≤10ms

On Load Capacity: 100%-120% 30s Protection, 125%-140% 15s Protection, ≥150% 5s Protection

Send email to us

Product Detail

Product Tags

Video

Overview

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: Vmaxpower

Model Number:: Inverter & Charger

Type:: Power frequency

Application:: Solar power stations, off-grid systems, home photovoltaic systems

Rated Power：: 3000W

Certificate:: CE,ISO 9001,ISO 14001

Warranty:: 2 Years

Output waveform:: Pure Sine Wave

Battery Rated Voltage:: 24V

Frequency:: 50/60Hz

Display:: Digital display

Color:: Blue

Operation Temperature:: -0 to 50C

Product Details

Product Characteristic

●USB Output and Mobile charge
●High Efficiency/Energy Saving
●Low self-Consumption below 1.2A.It can reach zero at energy saving mode.
●Make sure the load capacity is above 200W.or the inverter can not be restarted automatically
●Leading energy saving technology
●With the AVR function.AC voltage fluctuated is within +-5%
●Pure sine wave
●Extreme overload capacity and super load capacity
●Working Appliance:Air-conditioners.refrigerators.water pumps.TV.Light.fans and other household appliances and office appliances etc.
●Durable. LF transformer technology design.it is suitable for the poor working conditions or where the grid power is not stable
●LCD display /Digitized Display optional
●DC reverse polarity protection

If you want to travel, the car is already equipped with batteries

Pure Sine Wave

The output wave of this inverter is the pure sine wave， this waveform has the same quality as utility or home power supply.This waveform is suitable for most electrical equipment, appliances and tools.This pure sine wave inverter provides more functionality than the improved sine wave inverter because it is a cleaner form of electricity.Pure sine wave can also effectively reduce the noise of equipment.

●CPU Technology control
●Big Charging current. up to 70Amp.
●LCD display /Digitized Display optional：Grid powe.battery.AC output.Fault.Saving.
●Low voltage.Charging.
●Charging curren.Battery capacity.
●Intelligent battery management for maximum battery life
●Automatically switch between the grid and inverter mode
●Transfer time is below 4 ms if the grid power are cut off 220V/110V AC 50/60Hz is optional
●It can work with the generator
●Intelligent fan control mode.The fan work at Temperature ≥30℃.the inverter will protect by itself at temperature ≥100℃

Inverter is an indispensable part of photovoltaic system

product picture

inverter charger solar system vmaxpower factory-3

Product advantages and product performance comparison

More features

Voltage and Frequency

Adjustable voltage and Frequency,Customers could set one from 110V/115V/120V ( 220V/230V/240V) could choose 50Hz or 60Hz

Remote control

Support RS232 data coomunication and remote controller (max 100meters)

Application scenario

For shopping malls, medical institutions, construction sites, wasteland, etc., 3000W～8000W off-grid photovoltaic systems should be selected according to the load. If you need an inverter with a power of more than 8000W, please communicate with customer service for customization.

1000W-3000W inverters are recommended for ships, carports, toilets, and small-area systems.

Application scenario INVERTER CHARGER (7)

Places prone to power outages, elevators, schools in outlying suburbs...

Application scenario INVERTER CHARGER (10)

Travel camping, RV outing

Application scenario INVERTER CHARGER (9)

Household appliances, electric tools

Application scenario INVERTER CHARGER (8）

Engineering construction, photovoltaic system

Application scenario INVERTER CHARGER (5)

Technical Data

Model		500W	1000W	1500W	2000W	3000W	4000W	5000W	6000W	8000W
Rated Power		500W	1000W	1500W	2000W	3000W	4000W	5000W	6000W	8000W
Input	Voltage	AC165-275V / 85-135V
	Frequency	40-65HZ
Output	Voltage	220/230/240V（110/115/120V）Adjustable
	Frequency	50HZ-60HZ Adjustable
	Waveform	Pure Sine Wave
	THD	≤3%
	Efficiency	≥80%
Battery	Type	Optional
	Rated Voltage	DC12V		DC24V			DC48V
	Charging Current	0-30A Optional
Protection		Over Temperature / Over Load / Battery Discharge Voltage / Battery Over Voltage / AC Input High Voltage / Low Voltage Protection
Operating Mode		Normal, Energy Saving
Transfer Time		≤10ms
On Load Capacity		100%-120% 30s Protection, 125%-140% 15s Protection, ≥150% 5s Protection
Operating Range	Temp	0℃-50℃
	Humidity	10%-90% (No Condensing)

Battery Input Line Configuration

MODEL DC	500W	1000W	1500W	2000W	3000W	4000W	5000W	6000W	8000W
12V	10㎟	16㎟	——	——	——	——	——	——	——
24V	——	——	16㎟	16㎟	25㎟	——	——	——	——
48V	——	——	——	——	——	16㎟	25㎟	25㎟	35㎟

AC110V Input and Output Wire Configuration

MODEL LINE	500W 110VAC	1000W 110VAC	1500W 110VAC	2000W 110VAC	3000W 110VAC	4000W 110VAC	5000W 110VAC	6000W 110VAC	8000W 110VAC
L-IN	≥1㎟	≥2㎟	≥3㎟	≥4㎟	≥6㎟	≥8㎟	≥10㎟	≥12㎟	≥16㎟
N-IN	≥1㎟	≥2㎟	≥3㎟	≥4㎟	≥6㎟	≥8㎟	≥10㎟	≥12㎟	≥16㎟
Ground Wire	≥1㎟	≥2㎟	≥3㎟	≥4㎟	≥6㎟	≥8㎟	≥10㎟	≥12㎟	≥16㎟
L-OUT	≥1㎟	≥2㎟	≥3㎟	≥4㎟	≥6㎟	≥8㎟	≥10㎟	≥12㎟	≥16㎟
N-OUT	≥1㎟	≥2㎟	≥3㎟	≥4㎟	≥6㎟	≥8㎟	≥10㎟	≥12㎟	≥16㎟

AC220V Input and Output Wire Configuration

MODEL LINE	500W 200VAC	1000W 220VAC	1500W 220VAC	2000W 220VAC	3000W 220VAC	4000W 220VAC	5000W 220VAC	6000W 220VAC	8000W 220VAC
L-IN	≥0.5㎟	≥1㎟	≥1.5㎟	≥2㎟	≥3㎟	≥4㎟	≥5㎟	≥6㎟	≥10㎟
N-IN	≥0.5㎟	≥1㎟	≥1.5㎟	≥2㎟	≥3㎟	≥4㎟	≥5㎟	≥6㎟	≥10㎟
Ground Wire	≥0.5㎟	≥1㎟	≥1.5㎟	≥2㎟	≥3㎟	≥4㎟	≥5㎟	≥6㎟	≥10㎟
L-OUT	≥0.5㎟	≥1㎟	≥1.5㎟	≥2㎟	≥3㎟	≥4㎟	≥5㎟	≥6㎟	≥10㎟
N-OUT	≥0.5㎟	≥1㎟	≥1.5㎟	≥2㎟	≥3㎟	≥4㎟	≥5㎟	≥6㎟	≥10㎟

VMAXPOWER INVERTER WITH CHARGER

Our distributors have always trusted us, we guarantee quality, provide certificates, and smile service. His customers also like our products very much.

2009 Multifit Establis , 280768 Stock Exchange

— MULTIFIT

Beijing Multifit Electrical Technology Co.,Ltd

12⁺Years in Solar Industry 20⁺CE Certificates

— MULTIFIT

Beijing Multifit Eelectrical Technology Co.,Ltd

Multifit Green energy. Here let ou enjoy one-stop shopping. Factory direct delivery.

— MULTIFIT

Beijing Multifit Eelectrical Technology Co.,Ltd

Package & Shipping

Batteries have high requirements for transportation.
For questions about sea transportation, air transportation and road transportation, please consult us.
